Type R/B/S Platinum Rhodium Precious Metal Armoured Thermocouple Wire

Short Description:


Product Detail

FAQ

Product Tags

ntroducing the Wholesale Pt/PtRh R/B/S Type High Temperature Platinum Rhodium Precious Metal Armoured Thermocouple Wire!

Are you in need of a thermocouple that can handle high temperatures like a champ? Look no further! Our “Noble Metal” thermocouples, specifically the Type R, S, and B thermocouples, are perfect for your high temperature applications.

But let’s talk about the star of the show – the Platinum Rhodium Assembling Type Thermocouple. This bad boy is widely used in production places with high temperatures, making it an absolute must-have. It’s the go-to choice for measuring temperature in the glass and ceramic industry, as well as industrial salting.

Now, let’s dive into the details. Our thermocouple wire comes with various insulation materials to suit your needs – PVC, PTFE, FB, or whatever you desire. We’re all about customization here!

And the applications? Oh boy, we’ve got you covered. Whether you need it for heating gas burners in ovens, cooling freezers, protecting engines, or controlling high temperatures in iron casting, this thermocouple wire is your ultimate solution. It’s versatile, reliable, and ready to tackle any temperature-related challenge you throw at it.

So, why wait? Get your hands on the Wholesale Pt/PtRh R/B/S Type High Temperature Platinum Rhodium Precious Metal Armoured Thermocouple Wire from Shanghai Tankii Alloy Material Co., Ltd. today! Don’t miss out on this opportunity to elevate your temperature measurement game. Order now and experience the power of precision!

Parameter:

Chemical Composition
Conductor Name Polarity Code Nominal Chemical Composition /%
Pt Rh
Pt90Rh Positive SP 90 10
Pt Negative SN,RN 100
Pt87Rh Positive RP 87 13
Pt70Rh Positive BP 70 30
Pt94Rh Negative BN 94 6
Working temperature range
Dia. /mm Type Long time working temp./ ºC Short time working temp. / ºC
0.5 S 1300 1600
0.5 R 1300 1600
0.5 B 1600 1700

微信图片_20250805110322 8 6 详情页通用版-250314
