1.6mm thermal spray wire 45CT for Combustion Furnace

Short Description:

Thermal spraying wire in a wide range of alloys for high-temperature corrosion protection, bonding layers, build-up coating and sealing.
Nickel based alloy Thermal Spray wire
45CT is a  nickel chromium titanium wire specifically designed for arc spraying. It produces dense, well-bonded coatings with excellent corrosion resistance and good wear resistance. It is highly resistant to sulfur and vanadium atmospheres up to 1825° F. It has proven to be particularly effective as a protective arc spray coating for boiler tubes in black liquor recovery boilers and coal fired utility boilers.
This alloy is a nickel aluminium titanium alloy characterized strong resistance to high temperature corrosion oxidation.
 Typical applications for 45CT are widely used in combustion furnace,Boiler water wall tube, fan blade.


Product Detail

Product Tags

Thermal spray wire 1.6mm 2.0mm 3.175mm
Thermal spraying wire in a wide range of alloys for high-temperature corrosion protection, bonding layers, build-up coating and sealing.

Nickel based alloy Thermal Spray wire

45CT is a  nickel chromium titanium wire specifically designed for arc spraying. It produces dense, well-bonded coatings with excellent corrosion resistance and good wear resistance. It is highly resistant to sulfur and vanadium atmospheres up to 1825° F. It has proven to be particularly effective as a protective arc spray coating for boiler tubes in black liquor recovery boilers and coal fired utility boilers.

This alloy is a nickel aluminium titanium alloy characterized strong resistance to high temperature corrosion oxidation.
Typical applications for 45CT are widely used in combustion furnace,Boiler water wall tube, fan blade.

Normal composition%

Cr      Ni      C Mn Fe S Si Cu Ti P Other
42-46      Bal. 0.01-0.1 ≤0.2 ≤0.5 ≤0.015 ≤0.2 ≤0.5 0.3-1.0 ≤0.02 ≤0.5

Typical Deposit Characteristics

Coating Harness Coating Strength  Yield Strength  Elongation
45 HRC 48Mpa 295Mpa  ≤22%

Specific heat capacity

Melting point (ºC) 1450
Max continuous operating temperature in air (ºC) 1250
Magnetic properties non-magnetic
